The new Victron high-performance EV charging station-EV Charging Station
The Victron Wallbox has three -phase and single -phase skills and delivers a maximum of 22 kW alternating current in three -phase mode or 7.3 kW in single -phase mode. Equipped with Wi-Fi communication Wi-Fi: 802.11 B/G/N for configuration and surveillance. The internal Wi-Fi module can be configured for both the initial setup and for monitoring in Access Point mode or in station mode.
The Victron charging station has a 4.3-inch LCD touchscreen for monitoring and control as well as light ring for the quick display of the device status around the charging connection to quickly determine the device status. The light ring can be programmed via the web interface in such a way that depending on the current state (separated, loaded, loaded, loaded, etc.), it shows different lighting effects. The aim is to help the user signal the current state from a distance.
Two working modes available: Manual mode for configuring the output current
The manual mode enables a configurable output current between 6-32a. The charging capacity is controlled in two ways: via the slider on the LCD touchscreen or via the website. It enables manual starting or stopping the charging process when a vehicle is connected to the charging station.
Automatic mode to ensure maximum efficiency of the PV system. It recognizes when excess energy is available and only uses this energy to charge the vehicle.
Integration with GX devices
The EV charging station can be configured and monitored via the GX screen devices and the remote console. Several options are available in the VRM portal: real-time reports, custom reports for configurable periods, extended functions such as remote firmware update.
