The Growatt SPH10000TL3 BH-UP hybrid inverter is a state-of-the-art solution for solar projects. With intelligent load management, a wide battery voltage range of 100-550 V, and a VPP interface, it offers flexibility and efficiency. The inverter supports solar systems with a total output of up to 15 kW and enables an uninterruptible power supply. With these features, the SPH10kTL3 BH-UP is the ideal solution for flexible and reliable solar systems.
About the SPH10kTL3 BH-UP inverter
100% three-phase asymmetric output
Intelligent power control at phase level
Wide battery voltage range 100-550 V
UPS function with 10 ms switchover time
VPP interface
Scalable system configuration
DC/AC Type II SPD
DC/AC ratio up to 1.5
Two MPP trackers (maximum power point)
Intelligent load control via dry contact
Hybrid inverter
Unlike conventional inverters, hybrid inverters offer the option of not only feeding the generated solar power into the power grid, but also storing it in batteries. This allows the stored solar power to be used even when the sun is not shining. Another function of hybrid inverters is to optimize a household's power consumption by giving priority to using the generated solar power directly in the household before feeding it into the grid. This leads to a reduction in energy costs and less dependence on expensive grid power.
Operating modes – Configurable depending on system requirements
Online mode
Different operating modes can be set for optimal system integration of the SPH inverter. When entering directly on the device, a priority mode can only be set for a specific period of time. When using the online platform, up to three time periods can be set for the priority mode (paid accessories are required to use this function).
Load first:In the standard "Load first" mode, the connected loads (consumers) are supplied with energy first. As soon as the PV energy is sufficient for the load, the excess energy is fed into the battery. If the battery is fully charged or no battery is connected, the remaining energy is fed into the grid.
Battery first:In this mode, the inverter first fully charges the battery with the maximum possible solar power. If the PV power is insufficient, the grid charging function can also be activated.
Grid first:In this mode, the PV energy generated is first fed into the grid. The switch-on and switch-off times for this mode can be set here, as well as the power rate.
Backup mode:
If there is no longer any grid voltage at the device, e.g., due to a short-term power failure or blackout, the Growatt SPH automatically switches to backup mode. This ensures the supply of the AC output via the EPS LOAD connection. The required energy is supplied solely by the solar system and the battery. If the PV system also fails, the battery secures the AC supply until it is discharged. If necessary, the automatic switch to this mode can also be deactivated.
Maximum Power Point Tracking
By using Maximum Power Point Tracking (MPPT) technology, a solar system can achieve optimum yield. The MIC inverter is equipped with an MPPT that adjusts the optimum ratio of voltage and current throughout the day according to the solar radiation and the module temperature of the solar modules. With its wide MPPT voltage range, many solar modules can be connected, enabling efficient energy generation. This advantage is particularly evident when the sky is partly cloudy and the light intensity changes continuously.
Intelligent load management
The inverter's integrated smart load control enables precise and efficient control of energy consumption. The use of a potential-free contact allows electrical consumers to be controlled intelligently and prioritized. This function enables automatic detection of energy requirements and optimal use of the available energy. Smart load management ensures optimal distribution of energy and thus contributes to efficient use. With intelligent load control via the dry contact, the inverter is able to optimize the energy flow and ensure efficient operation of your solar system.
Growatt monitoring platform
By using the optional accessories from the Shine series, you can use the Growatt monitoring platform. This platform is available as a smartphone app for iOS and Android as well as in a web version. The Shine accessories must be purchased separately, but use of the platform is free of charge. Shine allows you to configure and monitor all your Growatt products, and also enables you to view your self-consumption and track trends.
The following Shine options are compatible with the SPH series:
ShineWiFi-X
ShineLink-X
Shine4G-X
ShineMaster
Technical data
Recommended module power: up to 15 kW
Max. DC voltage: 1000V
Start-up voltage: 120 V
MPPT voltage range: 120-1000 V/600 V
Battery voltage range: 100–550 V
Max. charging/discharging current: 25 A
Continuous charging/discharging power: 10 kW
AC rated power: 10 kW
Max. apparent power: 10 kVA
Max. AC output power: 10 kW
Max. output current: 15.2 A
AC rated voltage range: 230/400 V (310~476 V)
AC mains frequency range: 50/60 Hz (45Hz-55Hz/55Hz-65Hz)
Enclosure rating: IP65
Maximum efficiency of 98.2%
Dimensions: 505 x 453 x 198 mm
Weight: 30 kg
Scope of delivery
1x Growatt SPH10000TL3 BH-UP inverter
Note on Growatt inverters when used with batteries
Please note that MIN, MOD, SPH, and SPA series inverters may only be operated with original Growatt batteries. All Growatt inverters sold in Europe are not compatible with lead-acid batteries. Using them may result in malfunctions or damage to the devices.
