Data / order no.:
|
CSX12185-1800A
|
|
EAN
|
4250561730625
|
|
Nominal voltage
|
12.8V
|
|
Technology
|
Lithium LiFePO4
|
|
Kälteprüfstrom
|
CCA 1800A
|
|
Operating voltage
|
11.0V - 15.6V
|
|
Endpolart
|
Car SAE cone standard / plus right front
|
|
Shift
|
0 (positive pole front right)
|
|
Maße
|
315 x 174 x 190mm (incl. connector)
|
|
Installation position
|
any, standing, lying, sideways, upright
|
|
Weight
|
12.0kg
|
|
Reference to lead
|
See Finding the right starter battery
|
|
Guarantee
|
2 years
|
|
Cell type
|
HDP Heavy Duty Pouch cells
|
|
Application parallel circuit
|
yes, max. 4 pieces of the same type possible
|
|
Applying series switching
|
yes, 2 batteries in series on 24V
|
|
Capacity
|
|
Capacity at 25°C
|
85Ah
|
|
Capacity at 0°C
|
68Ah
|
|
Capacity at -25°C
|
43Ah
|
|
Energy content at 25°C
|
1088Wh
|
|
Lifetime
|
|
Start cycles
|
>100,000 (<3sec.)
|
|
Cycles / service life at 50% DoD
|
>5000
|
|
Cycles / service life at 70% DoD
|
|
|
Cycles / service life at 80% DoD
|
>2500
|
|
Peak discharge current / 3 sec
|
1800A
|
|
Continuous discharge current
|
160A
|
|
Recommended continuous discharge current
|
|
|
Recommended battery cut-off / system
|
11.0V
|
|
Load
|
|
Final charge voltage
|
14.2V - 14.6V
|
|
Conservation charge
|
13.3 - 13.5V
|
|
Max. Charging current / charging time / not Lima
|
85A / 60min
|
|
Recommended charging current / not Lima
|
43A / 120min
|
|
Insert temp repair on discharge
|
minus 20°C to plus 90°C
|
|
Recommended storage temperature
|
-45°C to 70°C / max 95% humidity
|
|
Protection class
|
IP56
|
|
Storage
|
60 - 80% / charge every 6 months in storage
|
|
Self-discharge
|
1.5 - 3% / month
|
|
Battery Management System
|
|
BMS built in
|
Multi-Dynamic-BMS
|
|
&overload protection
|
1800A
|
|
Charging programs
|
CCCV / IU / IUoU / Lead-Säure
|
|
Charging protection / control
|
yes,
|
|
Undervoltage protection
|
8.0V
|
|
Discharge current limitation (duration)
|
300A
|
|
&overvoltage protection
|
15.6V
|
|
Balancing
|
Active balancing in every state of charge
|
|
Short-circuit proof
|
Yes
|
|
Temperature monitoring / protection
|
Yes
|
|
Remote monitoring integrated with APP
|
n/a
|
|
Bluetooth
|
n/a
|
|
Conformity specifications
|
|
Certification
|
UN38.3 | MSDS | CE | RoHS | ECE-R10
|
|
Transport classification
|
UN3480
|
